Model No. 1401: Runabout High Speed Launch

Model by: NGH
Made when: April 1916 (??)
Possible model scale: 1/16
Model length (ca.): 24.9" (63.2cm)
Implied vessel LOA at 1/16 (ca.): 33' 2" (10.1m)
Power/Sail: P
Vessel Type: High Speed Launch (0); Patrol Boat (1)

Vessels from this model:
0 built, modeled by NGH

Original text on model:
"Model by NGH about 1913 [sic. 1916?]
Suggestion for high speed launch" (Source: Original handwritten annotation on model. Undated.)

Model identification:
"Newly identified model. Compare with drawing 005-071 (HH.5.00385) 'Preliminary for 33' Runabout Launch, 33' O.A.' of May 31, 1916, which, when overlaid to this model, provides a perfect match. This suggests that either the model was not made as noted in 'about 1913' but in the spring of 1916, or that the drawing was made three years after the model had been made." (Source: van der Linde, Claas. November 4, 2021.)

"Compare also with 'April 1916. Model & design for Runabout power boat for Buzzards Bay. Model 3/4in scale [1/16]. Length o.a. 31ft 10in. W.L. 32ft 0in. Stern 8ft 6in. readth w.l. 7ft 10in. Draft to rabbate 15 1/4in. ... Disp[lacement] 100.4cuft + Keel 3.7 = 104.1cuft = 6666lbs ...' in Design Book No 5, p. 96." (Source: van der Linde, Claas. March 6, 2021.)

Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.
